SOG
=Optisches Spezialglas 320 - 2500nm |
Q=
Fernes UV Quarz 170 - 2700nm |
| |
Two Clear
windows |
|
Path
lengths10, 20, 40, 50, 100 mm |
|
'Z'
dimensions: 8.5,15 & 20mm |
|
M6 screw
Connectors (see
accessories for spares) |
|
Designed
for use in spectrophotometers with
a small collimated or focused beam |
| |
 |
 |
|
|
"Z" dimension
is critical as the cell sample compartment must be correctly aligned
|
| in
the instrument light beam, see chart below |
|
Fully masked
cell with round aperture, dimensions see charts below, optimized for
|
| the
best flow characteristics for instruments with a narrow beam geometry
|
| Starna
Typ
|
Glas-
material |
Schicht-
dicke |
Externe
|
Sample
Chamber |
'Z'
Dimension
|
Nominal
Volume
|
| Weite
|
Länge
|
Höhe
|
Durchm
|
Länge
|
| Nr
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
ml
|
| 585.3
|
SOG/Q
|
10
|
12.5
|
12.5
|
45
|
3
|
10
|
8.5,
15, 20 |
0.070
|
| 585.3
|
SOG/Q
|
20
|
12.5
|
12.5
|
38.5
|
3
|
20
|
8.5,
15, 20 |
0.140
|
| 585.3
|
SOG/Q
|
40
|
12.5
|
12.5
|
38.5
|
3
|
40
|
8.5,
15, 20 |
0.280
|
| 585.3
|
SOG/Q
|
50
|
12.5
|
12.5
|
38.5
|
3
|
50
|
8.5,
15, 20 |
0.350
|
| 585.3
|
SOG/Q
|
100
|
12.5
|
12.5
|
38.5
|
3
|
100
|
8.5,
15, 20 |
0.700
|
|
